Unshrouded header connector with 8 positions and 2 rows, featuring a 2.54mm pitch. Male pin contacts made of bronze with gold, GXT plating and a mating length of 0.318 inches. Rated for 3A current and 1.5kV voltage, with a straight, through-hole mounting orientation. Operating temperature range from -65°C to 125°C.
Voltage Rating1.5kV
Current Rating3A
MountingThrough Hole
Quick Jump:
Technical Specifications
Amphenol 54102-S30-04 technical specifications.
General
Color
Black
Contact Gender
Male
Contact Material
Bronze
Contact Mating Length
0.318inch
Contact Plating
Gold, GXT
Contact Post Length
3.05mm
Contact Type
Male Pin
Current Rating
3A
Depth
4.83mm
Gender
Male
Housing Color
Black
Length
10.16mm
Max Operating Temperature
125°C
Min Operating Temperature
-65°C
Max Voltage Rating (AC)
1.5kV
Mount
Through Hole
Number of Contacts
8
Number of Positions
8
Number of Rows
2
Orientation
Straight
Package Quantity
100
Packaging
Bulk
Pitch
2.54mm
Radiation Hardening
No
RoHS Compliant
Yes
Row Spacing
0.1inch
Series
BERGSTIK®, MezzSelect™, Basics+
Termination
Solder
Voltage Rating
1.5kV
Compliance
RoHS
Compliant
Datasheet
Amphenol 54102-S30-04 Datasheet
Download the complete datasheet for Amphenol 54102-S30-04 to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
