30-position, 2-row shrouded header with straight orientation and 2.54mm pitch. Features male pin contacts made of bronze with gold, GXT plating and a 3A current rating. Mounts via through-hole termination with a 3.05mm contact post length and 0.23-inch mating length. Black housing, 1kV voltage rating, and lead-free construction.
Voltage Rating1kV
Current Rating3A
MountingThrough Hole
Quick Jump:
Technical Specifications
Amphenol 69168-130HLF technical specifications.
General
Color
Black
Contact Material
Bronze
Contact Mating Length
0.23inch
Contact Plating
Gold, GXT
Contact Post Length
3.05mm
Contact Type
Male Pin
Current Rating
3A
Depth
8.08mm
Gender
Male
Housing Color
Black
Lead Free
Lead Free
Length
38.1mm
Max Voltage Rating (AC)
1kV
Mount
Through Hole
Number of Contacts
30
Number of Positions
30
Number of Rows
2
Orientation
Straight
Package Quantity
100
Packaging
Bulk
Pitch
2.54mm
Radiation Hardening
No
RoHS Compliant
Yes
Row Spacing
0.1inch
Series
Mini-PV™, Basics+
Termination
Solder
Voltage Rating
1kV
Width
7.7mm
Compliance
RoHS
Compliant
Datasheet
Amphenol 69168-130HLF Datasheet
Download the complete datasheet for Amphenol 69168-130HLF to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
