This 8-position modular receptacle features 2 ports and 8 contacts, with a through hole mount and a USB 2.0 standard. It has a silver color and a copper alloy contact material with a gold and tin plating. The receptacle is lead-free and RoHS compliant, with a flammability rating of UL94 V-0. It is packaged in a rail/tube format with 41 units per package.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Amphenol 72309-8014BLF datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
| Color | Silver |
| Contact Material | Copper Alloy, Copper |
| Contact Plating | GXT, Gold, Tin, Matte |
| Depth | 17mm |
| Flammability Rating | UL94 V-0 |
| Gender | Receptacle |
| Insulation Color | White |
| Lead Free | Lead Free |
| Length | 13.1mm |
| Mount | Through Hole, Horizontal |
| Number of Contacts | 8 |
| Number of Ports | 2 |
| Number of Positions | 8 |
| Orientation | Right Angle |
| Package Quantity | 41 |
| Packaging | Rail/Tube |
| Plating | Nickel |
| Reach SVHC Compliant | No |
| RoHS Compliant | Yes |
| Termination | Solder |
| USB Standard | USB 2.0 |
| RoHS | Compliant |
