Circular connector with 4 male pin contacts, designed for solder termination and cable mounting. Features a straight, free-hanging orientation with a 13A current rating and operating temperatures from -55°C to 125°C. Constructed with an aluminum shell and body, both plated in cadmium, and utilizes copper alloy contacts plated with silver. Meets MIL-DTL-5015 military standards and holds UL and CSA approvals.
Current Rating13A
MountingFree Hanging, Cable
Quick Jump:
Technical Specifications
Amphenol 97-3107A-14S-2P technical specifications.
General
| Approvals | UL, CSA |
| Body Material | Aluminium |
| Body Plating | Cadmium |
| Contact Gender | Male |
| Contact Material | Copper Alloy, Brass, Copper |
| Contact Plating | Silver |
| Contact Type | Pin |
| Current Rating | 13A |
| Length | 37.13mm |
| Max Operating Temperature | 125°C |
| Military Standard | MIL-DTL-5015 |
| Min Operating Temperature | -55°C |
| Mount | Free Hanging, Cable |
| Number of Contacts | 4 |
| Number of Positions | 4 |
| Orientation | Straight |
| Package Quantity | 1 |
| Packaging | Bulk |
| Plating | Cadmium, Chromate |
| Radiation Hardening | No |
| Reach SVHC Compliant | No |
| RoHS Compliant | No |
| Series | 97 |
| Shell Material | Aluminium |
| Shell Plating | Cadmium |
| Shell Size | 14 |
| Strain Relief | No (Without) |
| Termination | Solder |
Compliance
| RoHS | Not CompliantNo |
