Board connector, male, right angle orientation, featuring 6 contacts arranged in 2 rows with a 2mm pitch. This plug connector utilizes copper alloy and bronze male pin contacts with gold plating for reliable interconnection. Rated for 2A current and 650V voltage, it operates within a temperature range of -40°C to 105°C and mounts via through-hole termination. The cream-colored insulator housing ensures durability and compliance with RoHS standards.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Amphenol 98464-G61-06LF datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
| Color | Cream |
| Contact Gender | Male |
| Contact Material | Copper Alloy, Bronze |
| Contact Mating Length | 0.157inch |
| Contact Plating | Gold, GXT |
| Contact Post Length | 2.5mm |
| Contact Type | Male Pin |
| Current Rating | 2A |
| Depth | 7.9mm |
| Gender | Male |
| Housing Color | Cream |
| Lead Free | Lead Free |
| Length | 8mm |
| Max Operating Temperature | 105°C |
| Min Operating Temperature | -40°C |
| Mount | Through Hole |
| Number of Contacts | 6 |
| Number of Positions | 6 |
| Number of Rows | 2 |
| Orientation | Right Angle |
| Package Quantity | 200 |
| Packaging | Bulk |
| Pitch | 2mm |
| Radiation Hardening | No |
| RoHS Compliant | Yes |
| Row Spacing | 0.079inch |
| Series | Minitek |
| Termination | Solder |
| Voltage Rating | 650V |
| Width | 5.9mm |
| RoHS | Compliant |
