25-way, 2-row D-Subminiature receptacle with right-angle, through-hole mounting. Features gold-plated bronze signal contacts and a steel, metal shell. Operates within a temperature range of -40°C to 85°C with a 5A current rating and 470pF capacitance.
PackageMetal
Capacitance470pF
Current Rating5A
MountingThrough Hole, Panel
Quick Jump:
Technical Specifications
Amphenol FCE17-B25SA-410 technical specifications.
General
| Body Material | Steel, Metal |
| Capacitance | 470pF |
| Package/Case | Metal |
| Color | Black |
| Contact Material | Bronze |
| Contact Plating | Gold |
| Contact Type | Signal |
| Current Rating | 5A |
| Depth | 18.64mm |
| Gender | Receptacle |
| Lead Free | Lead Free |
| Length | 53.04mm |
| Material | Metal |
| Max Operating Temperature | 85°C |
| Min Operating Temperature | -40°C |
| Mount | Through Hole, Panel |
| Number of Contacts | 25 |
| Number of Ports | 1 |
| Number of Positions | 25 |
| Number of Rows | 2 |
| Orientation | Right Angle |
| Package Quantity | 40 |
| Packaging | Bulk |
| Pitch | 2.76mm |
| Radiation Hardening | No |
| Reach SVHC Compliant | No |
| Series | FCE17 |
| Shell Size | B |
| Termination | Solder |
| Width | 18.52mm |
Compliance
| RoHS | Compliant |
