9-way, female D-Subminiature connector with straight orientation and solder termination. Features a steel metal shell, bronze contacts with gold plating, and a 5A current rating. This component offers a capacitance of 820pF and operates within a temperature range of -40°C to 85°C. Designed for free hanging or panel mounting, it has a pitch of 2.74mm.
PackageMetal
Capacitance820pF
Current Rating5A
MountingFree Hanging, Panel
Quick Jump:
Technical Specifications
Amphenol FCE17-E09SM-240 technical specifications.
General
| Body Material | Steel, Metal |
| Capacitance | 820pF |
| Package/Case | Metal |
| Color | Black |
| Contact Material | Bronze |
| Contact Plating | Gold |
| Contact Type | Signal |
| Current Rating | 5A |
| Depth | 16.73mm |
| Gender | Female |
| Length | 30.81mm |
| Max Operating Temperature | 85°C |
| Min Operating Temperature | -40°C |
| Mount | Free Hanging, Panel |
| Number of Contacts | 9 |
| Number of Ports | 1 |
| Number of Positions | 9 |
| Number of Rows | 2 |
| Orientation | Straight |
| Package Quantity | 100 |
| Packaging | Bulk |
| Pitch | 2.74mm |
| Plating | Tin |
| Radiation Hardening | No |
| Reach SVHC Compliant | No |
| RoHS Compliant | Yes |
| Series | FCE17 |
| Shell Material | Steel |
| Shell Size | E |
| Termination | Solder |
| Width | 12.55mm |
Compliance
| RoHS | Compliant |
