PT01E-12-10P(SR)

Datasheet

10 Pos Circular Connector, 7.5A, 600V, Solder, MIL-DTL-26482, Aluminum

Amphenol

PT01E-12-10P(SR)

Name: PT01E-12-10P(SR) Amphenol
Brand: Amphenol
SKU: PT01E-12-10P(SR)

10 Pos Circular Connector, 7.5A, 600V, Solder, MIL-DTL-26482, Aluminum

Circular connector, 10-position, male pin contacts, solder termination, and straight orientation. Features aluminum body with cadmium plating, copper alloy contacts with gold plating, and a 7.5A current rating. Rated for 600V, operating temperature range of -55°C to 125°C, and meets MIL-DTL-26482 standards. Designed for cable mounting with a shell size of 12 and accommodates wire gauges from 20AWG to 24AWG. Environmentally resistant and UL approved.

Voltage Rating600V

Current Rating7.5A

MountingFree Hanging, Cable

Quick Jump:

Chat with Datasheet

Technical Specifications

Amphenol PT01E-12-10P(SR) technical specifications.

General

Approvals	UL
Body Material	Aluminium
Body Plating	Cadmium
Contact Gender	Male
Contact Material	Copper Alloy, Copper
Contact Plating	Gold
Contact Type	Pin
Current Rating	7.5A
Gender	Receptacle
Max Operating Temperature	125°C
Military Standard	MIL-DTL-26482
Min Operating Temperature	-55°C
Mount	Free Hanging, Cable
Number of Contacts	10
Number of Positions	10
Orientation	Straight
Package Quantity	1
Packaging	Bulk
Plating	Cadmium, Chromate
Radiation Hardening	No
Ratings	Environment Resistant
Reach SVHC Compliant	Unknown
RoHS Compliant	No
Shell Material	Aluminium
Shell Size	12
Termination	Solder
Voltage Rating	600V
Wire Gauge (Max)	24AWG
Wire Gauge (Min)	20AWG
