This 24V LED indicator features a 20mA current rating and a green illumination color. It is rated for IP67 and has a luminous intensity of 8mcd. The LED is available in a 201-style panel mount package and is compliant with RoHS regulations.
Package201
Voltage24V
Current20mA
Quick Jump:
Technical Specifications
Apem Q8F1CXXG24E technical specifications.
General
| Package/Case | 201 |
| Color | Green |
| Current | 20mA |
| Forward Current | 20mA |
| Illumination Color | Green |
| Lens Color | Green |
| Lens Style | Round, Flat |
| Lens Transparency | Diffused |
| Life (Hours) | 100Hour |
| Luminous Intensity | 8mcd |
| Operating Supply Voltage | 24V |
| Package Quantity | 25 |
| Ratings | IP67 |
| Reach SVHC Compliant | No |
| RoHS Compliant | Yes |
| Series | Q Series |
| Termination | Solder |
| Viewing Angle | 100° |
| Voltage | 24V |
Compliance
| RoHS | Compliant |
Datasheet
Apem Q8F1CXXG24E Datasheet
Download the complete datasheet for Apem Q8F1CXXG24E to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
