The 02200033 terminal block from BB Thermo-Technik features a nickel material construction with a green color finish. It has a female gender and a panel mount configuration. The terminal block measures 8mm in height, 26mm in length, and 16.5mm in width. It is rated for operation between -50°C and 120°C. The terminal block is part of the 0220 series and has a screw termination.
Package120
MountingPanel
Quick Jump:
Technical Specifications
BB Thermo-Technik 02200033 technical specifications.
General
| Package/Case | 120 |
| Color | Green |
| Gender | Female |
| Height | 8mm |
| Length | 26mm |
| Material | Nickel |
| Max Operating Temperature | 120°C |
| Min Operating Temperature | -50°C |
| Mount | Panel |
| Series | 0220 |
| Termination | Screw |
| Width | 16.5mm |
Compliance
| RoHS | Compliant |
Datasheet
BB Thermo-Technik 02200033 Datasheet
Download the complete datasheet for BB Thermo-Technik 02200033 to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
Product Images
