Technical Specifications
Belden 1419A060500 technical specifications.
General
Approvals
UL, CE, NEC
Color
Chrome
Conductor Material
Copper
Insulation Material
PVC
Jacket Material
PVC
Length
500foot
Max Operating Temperature
80°C
Min Operating Temperature
-20°C
Mount
Cable
Number of Conductors
4
Number of Pairs
2
Outside Diameter
6.3mm
Packaging
Spool
Reach SVHC Compliant
No
RoHS Compliant
Yes
Shielding
Shielded
Stranding
7 x 32
Voltage Rating
30V
DC Rated Voltage
300V
Weight
15lb
Wire/Cable Gauge
24AWG
Wire/Cable Type
Multi-Pair, Twisted Pair
Compliance
RoHS
Compliant
Datasheet
Belden 1419A060500 Datasheet
Download the complete datasheet for Belden 1419A060500 to view detailed technical specifications.
