Capacitance35pF
Voltage Rating300V
MountingCable
Quick Jump:
Technical Specifications
Belden 9451SB0101000 technical specifications.
General
Approvals
UL, CE, NEC
Capacitance
35pF
Color
Black
Conductor Material
Copper
Insulation Material
PP
Jacket Material
LSZH
Length
1000foot
Max Operating Temperature
105°C
Min Operating Temperature
-30°C
Mount
Cable
Number of Conductors
2
Number of Pairs
1
Outside Diameter
0.16inch
Packaging
Bulk
Reach SVHC Compliant
No
RoHS Compliant
Yes
Shielding
Shielded
Stranding
7 x 30
Voltage Rating
300V
DC Rated Voltage
300V
Weight
20lb
Wire/Cable Gauge
22AWG
Wire/Cable Type
Twisted Pair
Compliance
RoHS
Compliant
Datasheet
Belden 9451SB0101000 Datasheet
Download the complete datasheet for Belden 9451SB0101000 to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
