Wirewound potentiometer featuring 50kΩ resistance with a 5% tolerance. This 10-turn unit offers 2W power dissipation and 0.25% linearity. Designed for panel mounting with solder terminations, it operates from -40°C to 125°C and is RoHS compliant. The actuator measures 0.25 inches in diameter and 0.81 inches in length.
Resistance50kR
MountingPanel
Quick Jump:
Technical Specifications
Bourns 3590S-2-503L technical specifications.
General
Actuator Diameter
0.2497inch
Actuator Length
0.812inch
Depth
22.23mm
Diameter
22.23mm
Height
26.66mm
Lead Free
Lead Free
Length
39.22mm
Linearity
0.25%
Max Operating Temperature
125°C
Min Operating Temperature
-40°C
Max Power Dissipation
2W
Military Standard
Not
Mount
Panel
Number of Gangs
1
Number of Turns
10
Package Quantity
5
Packaging
Bulk
Radiation Hardening
No
Reach SVHC Compliant
No
Resistance
50kR
Resistance Tolerance
5%
Resistor Type
Wirewound
RoHS Compliant
Yes
Series
3590
Taper
Linear
Termination
Solder
Tolerance
5%
Type
Potentiometer
DC Rated Voltage
500V
Weight
19g
Compliance
RoHS
Compliant
Datasheet
Bourns 3590S-2-503L Datasheet
Download the complete datasheet for Bourns 3590S-2-503L to view detailed technical specifications.
