PackageSMD/SMT
MountingSurface Mount, Board, Through Hole, PCB
Power1.08W
Quick Jump:
Technical Specifications
Broadcom ASMT-AA00-ARR01 technical specifications.
General
Package/Case
SMD/SMT
Color
Orange
Forward Current
350mA
Illumination Color
Orange
Lens Style
Round
Luminous Flux
46lm
Max Current Rating
500mA
Max Operating Temperature
115°C
Min Operating Temperature
-40°C
Max Power Dissipation
1.15W
Mount
Surface Mount, Board, Through Hole, PCB
Package Quantity
500
Packaging
Tape and Reel
Power Dissipation
1.08W
Reach SVHC Compliant
No
RoHS Compliant
Yes
Test Temperature
25°C
Thermal Resistance of Package
10°C/W
Viewing Angle
140°
Wavelength
590nm
Compliance
RoHS
Compliant
Datasheet
Broadcom ASMT-AA00-ARR01 Datasheet
Download the complete datasheet for Broadcom ASMT-AA00-ARR01 to view detailed technical specifications.
