PackageRadial
MountingThrough Hole
Quick Jump:
Technical Specifications
Broadcom HLMP-LB63-PT0ZZ technical specifications.
General
Package/Case
Radial
Color
Blue
Height
10.5mm
Illumination Color
Blue
Lens Color
Blue
Lens Style
Elliptical
Lens Transparency
Diffused
Luminous Intensity
670mcd
Max Operating Temperature
85°C
Min Operating Temperature
-40°C
Mount
Through Hole
Package Quantity
2000
Packaging
Tape and Reel
RoHS Compliant
Yes
Viewing Angle
50°
Wavelength
470nm
Compliance
RoHS
Compliant
Datasheet
Broadcom HLMP-LB63-PT0ZZ Datasheet
Download the complete datasheet for Broadcom HLMP-LB63-PT0ZZ to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
