This Green 5-position D-Subminiature female power connector features a copper alloy contact material with gold plating and a current rating of 20A. It has a flammability rating of UL94 V-0 and is lead-free. The connector is available in a tray packaging with 10 pieces per package. It has a steel shell with a size of 3 and a termination of solder. The operating temperature range is -55°C to 125°C.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Conec 3005W5SXX56N40X datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
Conec 3005W5SXX56N40X technical specifications.
| Color | Green |
| Contact Material | Copper Alloy |
| Contact Plating | Gold |
| Contact Type | Power |
| Current Rating | 20A |
| Flammability Rating | UL94 V-0 |
| Gender | Female |
| Height | 12.9mm |
| Housing Color | Green |
| Lead Free | Lead Free |
| Length | 53.4mm |
| Max Operating Temperature | 125°C |
| Min Operating Temperature | -55°C |
| Mount | Through Hole, Edge, Board |
| Number of Positions | 5 |
| Number of Rows | 1 |
| Package Quantity | 10 |
| Packaging | Tray |
| Plating | Tin |
| RoHS Compliant | No |
| Shell Material | Steel |
| Shell Size | 3 |
| Termination | Solder |
| RoHS | Not Compliant |
Download the complete datasheet for Conec 3005W5SXX56N40X to view detailed technical specifications.
