Current Rating80A
MountingPanel, Surface Mount, Screw
Quick Jump:
Technical Specifications
Crydom D1D80 technical specifications.
General
Control Voltage
32V
Current Rating
80A
Depth
45.7mm
Height
23mm
Input Current
28mA
Input Type
DC
Isolation Voltage
2.5kV
Isolation Voltage-Max
2.5kV
Lead Free
Lead Free
Length
58.4mm
Load Current
80A
Max Input Current
28mA
Max Operating Temperature
80°C
Min Operating Temperature
-20°C
Max Output Current
80A
Max Output Voltage
100V
Max Supply Voltage (DC)
100V
Min Supply Voltage (DC)
0V
Max Surge Current
220A
Max Voltage Rating (DC)
100V
Mount
Panel, Surface Mount, Screw
Operating Supply Voltage
100V
Output Current
80A
Output Voltage
100V
Package Quantity
10
Radiation Hardening
No
Reach SVHC Compliant
No
RoHS Compliant
Yes
Series
1-DC Series
Termination
Screw
Throw Configuration
SPST
DC Rated Voltage
100V
Width
45.7mm
Compliance
RoHS
Compliant
Datasheet
Crydom D1D80 Datasheet
Download the complete datasheet for Crydom D1D80 to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
