Dual color LED emitter, featuring yellow and green illumination. This T-1 (3mm) standard LED offers a 2.1V forward voltage and 20mA current rating. With a luminous intensity of 5.8mcd and a broad 80° viewing angle, it operates across a wide temperature range from -55°C to 100°C. The nondiffused, domed lens style and snap-in mounting are complemented by wire lead termination. This RoHS compliant component is supplied in bulk packaging.
Voltage2.1V
Current20mA
Voltage Rating2.1V
Current Rating10mA
Quick Jump:
Technical Specifications
Dialight 558-3201-007F technical specifications.
General
| Approvals | UL |
| Color | Green, Yellow |
| Current | 20mA |
| Current Rating | 10mA |
| Depth | 4.83mm |
| Forward Current | 10mA |
| Illumination Color | Green, Yellow |
| Length | 4.83mm |
| Lens Color | Green, Yellow |
| Lens Size | 3mm |
| Lens Style | Round, Domed, Dome, Diffused, Colorless |
| Luminous Intensity | 5.8mcd |
| Max Operating Temperature | 100°C |
| Min Operating Temperature | -55°C |
| Mount | Snap in, Front |
| Number of Elements | 2 |
| Number of LEDs | 2 |
| Package Quantity | 100 |
| Packaging | Bulk |
| Radiation Hardening | No |
| Reach SVHC Compliant | No |
| RoHS Compliant | Yes |
| Series | 558 |
| Termination | Wire Leads |
| Viewing Angle | 80° |
| Voltage | 2.1V |
| Voltage Rating | 2.1V |
| DC Rated Voltage | 2.1V |
| Wavelength | 565nm |
Compliance
| RoHS | Compliant |
Datasheet
Dialight 558-3201-007F Datasheet
Download the complete datasheet for Dialight 558-3201-007F to view detailed technical specifications.
