Single color LED emitter, green illumination, featuring a 9.91mm domed lens. Operates with a forward current of 15mA and a voltage rating of 12V DC. Offers a luminous intensity of 110mcd and a wide operating temperature range from -25°C to 85°C. Panel mountable with solder termination, this RoHS compliant component is supplied in bulk packaging.
Voltage12V
Current15mA
Voltage Rating12V
Current Rating15mA
Quick Jump:
Chat with Datasheet
Sponsored by
Sign in to ask questions about the Dialight 608-1232-230F datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
Technical Specifications
Dialight 608-1232-230F technical specifications.
General
| Color | Green |
| Current | 15mA |
| Current Rating | 15mA |
| Depth | 9.91mm |
| Forward Current | 15mA |
| Illumination Color | Green |
| Lead Free | Lead Free |
| Length | 9.91mm |
| Lens Color | Green |
| Lens Size | 9.91mm |
| Lens Style | Round, Domed, Dome |
| Luminous Intensity | 110mcd |
| Max Operating Temperature | 85°C |
| Min Operating Temperature | -25°C |
| Mount | Panel |
| Number of Elements | 1 |
| Number of LEDs | 1 |
| Operating Supply Voltage | 12V |
| Package Quantity | 25 |
| Packaging | Bulk |
| Radiation Hardening | No |
| Reach SVHC Compliant | No |
| RoHS Compliant | Yes |
| Series | 608 |
| Termination | Solder |
| Voltage | 12V |
| Voltage Rating | 12V |
| DC Rated Voltage | 12V |
Compliance
| RoHS | Compliant |
Datasheet
Dialight 608-1232-230F Datasheet
Download the complete datasheet for Dialight 608-1232-230F to view detailed technical specifications.
