The EASY719-AB-RC relay module is a 12-input, 6-output device with a maximum operating temperature of 55°C and a minimum operating temperature of -25°C. It is designed for use with a 24V operating supply voltage and can handle an output current of 10A. The module is mounted on a DIN rail and has a package case type of module. It is part of the Easy 700 series and has an IP20 rating.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Eaton EASY719-AB-RC datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
Eaton EASY719-AB-RC technical specifications.
| Package/Case | Module |
| Depth | 58mm |
| Length | 110mm |
| Manufacturer Series | Easy 700 |
| Max Operating Temperature | 55°C |
| Min Operating Temperature | -25°C |
| Mount | DIN Rail |
| Number of Inputs | 12 |
| Number of Outputs | 6 |
| Operating Supply Voltage | 24V |
| Output Current | 10A |
| Output Type | RELAY |
| Ratings | IP20 |
| Reach SVHC Compliant | No |
| Series | EASY700 Series |
| Width | 107.5mm |
| RoHS | Compliant |
