24V DC axial fan with ball bearing, delivering 20.6 CFM airflow at 4100 RPM. Features a 60mm x 60mm x 25mm plastic housing with flange mounting and lead termination. Operates within a temperature range of -4°C to 70°C, consuming 1.3W of power with a noise level of 28 dBA.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Ebm-Papst 614NM datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
Ebm-Papst 614NM technical specifications.
| Airflow | 20.6CFM |
| Bearing Type | Ball |
| Package/Case | Axial |
| Depth | 60mm |
| Height | 25mm |
| Length | 60mm |
| Material | Plastic |
| Max Operating Temperature | 70°C |
| Min Operating Temperature | -4°C |
| Max Power Dissipation | 1.4W |
| Mount | Flanges |
| Noise | 28dBA |
| Noise Level | 28dBA |
| Operating Frequency | Not RequiredHz |
| Operating Supply Voltage | 24V |
| Packaging | Bulk |
| Power Consumption | 1.3W |
| Radiation Hardening | No |
| RPM | 4100RPM |
| Series | 600N |
| Size | 60mm |
| Speed | 4100RPM |
| Termination | Leads |
| Voltage Rating | 24V |
| Weight | 0.145lb |
| Width | 60mm |
| RoHS | Compliant |
