Current Rating1.1A
Quick Jump:
Technical Specifications
EPT 304-90064-01 technical specifications.
General
| Color | Grey |
| Contact Material | Copper Alloy, Nickel, Gold |
| Current Rating | 1.1A |
| Gender | Receptacle |
| Height | 15mm |
| Lead Pitch | 2.54mm |
| Length | 10.6mm |
| Mating Cycles | 400 |
| Max Operating Temperature | 125°C |
| Min Operating Temperature | -55°C |
| Number of Contacts | 48 |
| Number of Rows | 3 |
| Reach SVHC Compliant | No |
| RoHS Compliant | Yes |
| Termination | Through Hole |
| Width | 54.36mm |
Compliance
| RoHS | Compliant |
Datasheet
EPT 304-90064-01 Datasheet
Download the complete datasheet for EPT 304-90064-01 to view detailed technical specifications.
No datasheet is available for this part.
