Dual-core microcontroller SoC integrates 2.4 GHz Wi-Fi 4 and Bluetooth LE 5 connectivity for AIoT applications. The device uses an Xtensa LX7 32-bit dual-core CPU running up to 240 MHz with 512 KB SRAM and 384 KB ROM. It provides up to 45 programmable GPIOs plus I2C, I2S, SPI, UART, USB OTG, ADC, touch, SD/MMC host and TWAI interfaces. The QFN56 package operates from 3.0 V to 3.6 V and supports an extended temperature range up to 105 °C for the base ESP32-S3 variant.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Espressif Systems ESP32-S3 datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
| Product Type | SoC |
| CPU Core | Xtensa dual-core 32-bit LX7 |
| CPU Frequency | 240MHz |
| Wi-Fi Standard | IEEE 802.11b/g/n |
| Wi-Fi Band | 2.4GHz |
| Wi-Fi Channel Bandwidth | HT20/40MHz |
| Wi-Fi Data Rate | Up to 150Mbps |
| Bluetooth | Bluetooth LE v5.0 |
| SRAM | 512KB |
| ROM | 384KB |
| RTC SRAM | 16KB |
| GPIO Count | 45 |
| Supply Voltage | 3.0 to 3.6V |
| Operating Temperature | -40 to 105°C |
| Pins | 56 |
| Package | QFN56 (7*7) |
| ADC | 2 x 12-bit ADC, up to 20 channels |
| Interfaces | 2 I2C, 2 I2S, 4 SPI, 3 UART, USB OTG |
| Security Features | Secure Boot, Flash Encryption, Digital Signature, HMAC, AES, SHA, RSA, ECC, RNG |
| ECCN | 5A992.c |
| Ccats | G194398 |
| Hs Code | 8542399000 |
