GW33240090069

Capacitance uF = 3300 / Rated Voltage DC V = 400 / Tolerance = ±20 % / Polarity = Polar / Lifetime h = 5000 / Operating Temperature Min. °C = -40 / Operating Temperature Max. °C = 105 / Termination Type = Screw / Mounting Type = Flange Mount / Equivalent Series Resistance mOhm = 34 / Ripple Current A = 9.8 / Leakage Current mA = 10.57 / Series = GW / Diameter mm = 90 / Length mm = 69
