LFB47050030050

Capacitance uF = 47 / Rated Voltage DC V = 500 / Tolerance = -10 ... 30 % / Polarity = Polar / Lifetime h = 2500 / Operating Temperature Min. °C = -40 / Operating Temperature Max. °C = 85 / Termination Type = Solder Lug Terminal / Mounting Type = Stud Mount / Equivalent Series Resistance Ohm = 1 / Ripple Current mA = 600 / Leakage Current uA = 192 / Series = LFB / Diameter mm = 30 / Length mm = 50
