Right-angle D-subminiature connector, male, 15 positions, 2 rows, 2.54mm pitch, solder termination. Features copper alloy contacts with gold plating, rated for 6A current and 250V working voltage. Steel body with tin plating, PBT dielectric, and UL94 V-0 flammability rating. Operates from -55°C to 125°C with 250 mating cycles.
Voltage Rating250V
Current Rating6A
MountingThrough Hole
Quick Jump:
Technical Specifications
Harting 09652626812 technical specifications.
General
| Body Material | Steel, Metal |
| Body Plating | Tin |
| Contact Material | Copper Alloy, Nickel, Gold |
| Contact Plating | Gold |
| Contact Type | Signal |
| Current Rating | 6A |
| Dielectric Material | PBT |
| Flammability Rating | UL94 V-0 |
| Gender | Male |
| Height | 12.5mm |
| Length | 39.5mm |
| Material | Steel |
| Mating Cycles | 250 |
| Max Operating Temperature | 125°C |
| Min Operating Temperature | -55°C |
| Mount | Through Hole |
| Number of Contacts | 15 |
| Number of Ports | 1 |
| Number of Positions | 15 |
| Number of Rows | 2 |
| Orientation | Right Angle |
| Package Quantity | 100 |
| Packaging | Tray |
| Pitch | 2.54mm |
| Reach SVHC Compliant | No |
| RoHS Compliant | Yes |
| Termination | Solder |
| Test Voltage | 1kV |
| Width | 13.6mm |
| Working Voltage | 250V |
Compliance
| RoHS | Compliant |
