14-position, 2-row straight shrouded header receptacle with 2mm pitch. Features female copper contacts with gold plating, rated for 3A current and 120V voltage. Designed for crimp termination of discrete wire, accommodating 24-28AWG. Offers free hanging and panel mount options.
Voltage Rating120V
Current Rating3A
MountingFree Hanging, Panel
Quick Jump:
Technical Specifications
Harwin M80-4661405 technical specifications.
General
| Color | Black |
| Contact Gender | Female |
| Contact Material | Copper |
| Contact Plating | Gold |
| Contact Type | Female Socket |
| Current Rating | 3A |
| Gender | Receptacle |
| Mount | Free Hanging, Panel |
| Number of Contacts | 14 |
| Number of Positions | 14 |
| Number of Rows | 2 |
| Orientation | Straight |
| Package Quantity | 1 |
| Packaging | Bulk |
| Pitch | 2mm |
| Radiation Hardening | No |
| Reach SVHC Compliant | No |
| RoHS Compliant | Yes |
| Row Spacing | 0.079inch |
| Series | Datamate J-Tek |
| Termination | Crimp |
| Voltage Rating | 120V |
| Wire Gauge (Max) | 28AWG |
| Wire Gauge (Min) | 24AWG |
| Wire/Cable Type | Discrete |
Compliance
| RoHS | Compliant |
