12-position, 2-row, 2mm pitch shrouded header receptacle for board-to-board and cable mount applications. Features female socket contacts made from copper, bronze, and brass with gold plating, rated for 3A current and 120V AC. Straight, top-entry, free-hanging mount with a black housing and operating temperature range of -55°C to 125°C. Supports discrete wire termination via crimp, accommodating wire gauges from 28AWG to 24AWG.
Voltage Rating120V
Current Rating3A
MountingFree Hanging
Quick Jump:
Technical Specifications
Harwin M80-8881205 technical specifications.
General
| Color | Black |
| Contact Gender | Female |
| Contact Material | Copper, Bronze, Brass |
| Contact Plating | Gold |
| Contact Type | Female Socket |
| Current Rating | 3A |
| Depth | 8.15mm |
| Gender | Receptacle |
| Housing Color | Black |
| Length | 15.15mm |
| Max Current Rating | 3A |
| Max Operating Temperature | 125°C |
| Min Operating Temperature | -55°C |
| Max Voltage Rating (AC) | 120V |
| Mount | Free Hanging |
| Number of Contacts | 12 |
| Number of Positions | 12 |
| Number of Rows | 2 |
| Orientation | Straight |
| Package Quantity | 1 |
| Packaging | Bulk |
| Pitch | 2mm |
| Radiation Hardening | No |
| Reach SVHC Compliant | No |
| RoHS Compliant | Yes |
| Series | Datamate L-Tek |
| Termination | Crimp |
| Voltage Rating | 120V |
| Wire Gauge (Max) | 24AWG |
| Wire Gauge (Min) | 28AWG |
| Wire/Cable Type | Discrete |
Compliance
| RoHS | Compliant |
Datasheet
Harwin M80-8881205 Datasheet
Download the complete datasheet for Harwin M80-8881205 to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
Product Images
