White LED indicator light, 300lm luminous flux, 4.4W power consumption, and 15 LEDs. Features a 3m lead length, 16mm height, 330mm length, and 27.5mm width. Operates within a temperature range of -30°C to 50°C with a 24V DC rated voltage and IP65 ingress protection.
Package300
Quick Jump:
Technical Specifications
Idec LF1B-NC4P-2THWW2-3M technical specifications.
General
| Package/Case | 300 |
| Color | White |
| Height | 16mm |
| Lead Length | 3m |
| Length | 330mm |
| Luminous Flux | 300lm |
| Max Operating Temperature | 50°C |
| Min Operating Temperature | -30°C |
| Number of LEDs | 15 |
| Ratings | IP65 |
| DC Rated Voltage | 24V |
| Width | 27.5mm |
Compliance
| RoHS | Compliant |
Datasheet
Idec LF1B-NC4P-2THWW2-3M Datasheet
Download the complete datasheet for Idec LF1B-NC4P-2THWW2-3M to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
