Dual-channel peripheral driver IC featuring MOS technology for efficient power management. Offers a maximum output current of 9A with a continuous output current of 2.4A per channel. Operates within a supply voltage range of 16V to 40V, with a low on-state resistance of 11mR. Surface-mount SOIC package, halogen-free and lead-free, suitable for operation from -40°C to 150°C.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Infineon BTS5210G datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
| Package/Case | SOIC |
| Current | 3.9A |
| Halogen Free | Halogen Free |
| Height | 1.47mm |
| Lead Free | Lead Free |
| Length | 8.75mm |
| Max Operating Temperature | 150°C |
| Min Operating Temperature | -40°C |
| Max Output Current | 9A |
| Max Power Dissipation | 3.05W |
| Max Supply Current | 1.7mA |
| Max Supply Voltage | 40V |
| Mount | Surface Mount |
| Number of Channels | 2 |
| Number of Outputs | 2 |
| On-State Resistance | 11mR |
| Operating Supply Voltage | 40V |
| Output Current | 2.4A |
| Output Current per Channel | 2.4A |
| Package Quantity | 1 |
| Packaging | Tape and Reel |
| Reach SVHC Compliant | No |
| RoHS Compliant | Yes |
| Voltage | 16V |
| Width | 4mm |
| RoHS | Compliant |
Download the complete datasheet for Infineon BTS5210G to view detailed technical specifications.
