DF06S

International Rectifier DF06S Bridge, Single Phase Case type D 70 U(FM) 1 V U(RRM) 600 V

Package600

Current Rating1A

MountingSurface Mount

Quick Jump:

International Rectifier DF06S technical specifications.

Package/Case	600
Current Rating	1A
Forward Current	1A
Height	3.3mm
Lead Free	Contains Lead
Length	8.51mm
Max Forward Surge Current (Ifsm)	31A
Max Operating Temperature	150°C
Min Operating Temperature	-55°C
Max Repetitive Reverse Voltage (Vrrm)	600V
Max Reverse Current	5A
Mount	Surface Mount
Output Current	1A
Packaging	Bulk
Peak Non-Repetitive Surge Current	50A
RoHS Compliant	No
DC Rated Voltage	600V
Width	6.5mm

RoHS	Not Compliant
