Jaeger
532662006
Jaeger 5326 Series, 12 Way Cable Mount Connector Plug, Pin Contacts,Shell Size 2, Quick Connect, MIL-DTL-5015
Current Rating15A
MountingCable
Quick Jump:
Technical Specifications
Jaeger 532662006 technical specifications.
General
Contact Gender
Male
Contact Material
Silver
Contact Plating
Gold
Current Rating
15A
Gender
Male
Max Operating Temperature
100°C
Military Standard
MIL-DTL-5015
Min Operating Temperature
-50°C
Mount
Cable
Number of Contacts
12
Orientation
Straight
Ratings
IP50, IP40
RoHS Compliant
Yes
Series
5326
Shell Size
2
Termination
Solder
Compliance
RoHS
Compliant
Datasheet
Jaeger 532662006 Datasheet
Download the complete datasheet for Jaeger 532662006 to view detailed technical specifications.
