This 12-position shrouded header features a contact finish of TIN and a contact material of bronze with a tin plating. The insulation material is nylon with a natural color and a flammability rating of UL94 V-0. The header is lead-free and has a maximum operating temperature of 85°C and a minimum operating temperature of -25°C. It is designed for through-hole mount and has a pitch of 2.5mm.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the JST 12JQ-BT datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
| Contact Finish - Mating | TIN |
| Contact Material | Bronze, Tin |
| Contact Shape | Square |
| Contact Type | Female Socket |
| Flammability Rating | UL94 V-0 |
| Insulation Color | Natural |
| Insulation Material | Nylon |
| Lead Free | Lead Free |
| Mated Stacking Heights | 11.8mm |
| Max Operating Temperature | 85°C |
| Min Operating Temperature | -25°C |
| Mount | Through Hole |
| Number of Positions | 12 |
| Number of Rows | 1 |
| Packaging | Bulk |
| Pitch | 2.5mm |
| Series | JQ |
| Termination | Press-Fit |
| Voltage Rating | 250V |
| RoHS | Compliant |
