Surface mount tantalum capacitor, 3.3µF capacitance, 50V DC rated voltage, and 10% tolerance. Features a 2917 (7343 metric) case code, solid tantalum dielectric, and a maximum operating temperature of 125°C. This general-purpose component offers low leakage current of 1.7µA and an ESR of 2Ω. It is RoHS compliant and packaged on tape and reel.
Package2917
Voltage50V
Capacitance3.3uF
Voltage Rating50V
Quick Jump:
Technical Specifications
Kemet T491D335K050AT technical specifications.
General
| Capacitance | 3.3uF |
| Case Code (Imperial) | 2917 |
| Case Code (Metric) | 7343 |
| Package/Case | 2917 |
| Construction | Flat |
| Depth | 4.3mm |
| Dielectric Material | Tantalum |
| Dissipation Factor | 6% |
| ESR (Equivalent Series Resistance) | 2R |
| Failure Rate | 0.001% |
| Features | General Purpose |
| Height | 2.8mm |
| Height - Seated (Max) | 0.122inch |
| Lead Free | Lead Free |
| Lead Pitch | 3.6mm |
| Leakage Current | 1.7uA |
| Length | 7.3mm |
| Max Operating Temperature | 125°C |
| Min Operating Temperature | -55°C |
| Mount | Surface Mount, PCB |
| Package Quantity | 1 |
| Packaging | Tape and Reel |
| Radiation Hardening | No |
| Reach SVHC Compliant | No |
| Ripple Current | 274mA |
| RoHS Compliant | Yes |
| Series | T491 |
| Termination | SMD/SMT |
| Tolerance | 10% |
| Voltage | 50V |
| Voltage Rating | 50V |
| DC Rated Voltage | 50V |
| Width | 4.3mm |
Compliance
| RoHS | Compliant |
Datasheet
Kemet T491D335K050AT Datasheet
Download the complete datasheet for Kemet T491D335K050AT to view detailed technical specifications.
