The KB817-B is a general purpose optocoupler with a collector emitter breakdown voltage of 35V and a saturation voltage of 200mV. It can handle a maximum collector current of 50mA and a maximum power dissipation of 200mW. The device is packaged in a DIP-4 package and is suitable for operation over the temperature range of -30°C to 100°C. The KB817-B is RoHS compliant and is available in cut tape packaging.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Kingbright KB817-B datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
Kingbright KB817-B technical specifications.
| Package/Case | SMD/SMT |
| Collector Emitter Breakdown Voltage | 35V |
| Collector Emitter Saturation Voltage | 200mV |
| Fall Time | 3us |
| Forward Current | 50mA |
| Input Current | 50mA |
| Input Type | DC |
| Isolation Voltage | 5kV |
| Max Collector Current | 50mA |
| Max Input Current | 50mA |
| Max Operating Temperature | 100°C |
| Min Operating Temperature | -30°C |
| Max Power Dissipation | 200mW |
| Mount | Through Hole |
| Number of Channels | 1 |
| Output Voltage | 35V |
| Packaging | Cut Tape |
| Radiation Hardening | No |
| Reach SVHC Compliant | No |
| RoHS Compliant | Yes |
| Voltage | 6V |
| RoHS | Compliant |
