Uni-color LED light bar featuring two green segments with a 565nm wavelength. This through-hole mount component utilizes an epoxy package with diffused, square, domed lens style and a 3mm lens size. It operates with a 2.2V forward voltage and 20mA forward current, offering a luminous intensity of 25mcd and a wide 160° viewing angle. The component is lead-free, RoHS compliant, and rated for operation between -40°C and 85°C.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Lumex SSB-LX2500SGW datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
| Package/Case | Epoxy |
| Character Width | 8.89mm |
| Color | Green |
| Current | 25mA |
| Forward Current | 20mA |
| Height | 4.86mm |
| Illumination Color | Green |
| Lead Free | Lead Free |
| Length | 9.94mm |
| Lens Size | 3mm |
| Lens Style | Diffused, Square, Domed |
| Luminous Intensity | 25mcd |
| Max Operating Temperature | 85°C |
| Min Operating Temperature | -40°C |
| Mount | Through Hole, PCB |
| Number of Contacts | 4 |
| Number of Segments | 2 |
| Operating Supply Voltage | 2.2V |
| Package Quantity | 100 |
| Packaging | Bulk |
| Power Dissipation | 105mW |
| RoHS Compliant | Yes |
| Viewing Angle | 160° |
| Voltage Rating | 2.2V |
| Wavelength | 565nm |
| Width | 9.94mm |
| RoHS | Compliant |
