Green diffused dome round LED emitter, 3mm lens size, 2.2V operating voltage, 20mA forward current, 25mA current, 30mcd luminous intensity, 565nm wavelength, 60° viewing angle. Features a 2-contact termination, 85°C max operating temperature, and -40°C min operating temperature. This RoHS compliant component contains lead.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Lumex SSI-LXR1612GD datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
Lumex SSI-LXR1612GD technical specifications.
| Package/Case | T |
| Color | Green |
| Current | 25mA |
| Diameter | 3mm |
| Forward Current | 20mA |
| Height | 1.362inch |
| Illumination Color | Green |
| Lead Free | Contains Lead |
| Lens Color | Green |
| Lens Size | 3mm |
| Lens Style | Round, Domed, Dome |
| Lens Transparency | Diffused |
| Luminous Intensity | 30mcd |
| Max Operating Temperature | 85°C |
| Min Operating Temperature | -40°C |
| Number of Contacts | 2 |
| Operating Supply Voltage | 2.2V |
| Package Quantity | 100 |
| Packaging | Bulk |
| Reach SVHC Compliant | No |
| RoHS Compliant | Yes |
| Termination | Wire |
| Viewing Angle | 60° |
| Voltage | 2.2V |
| DC Rated Voltage | 2.6V |
| Wavelength | 565nm |
| RoHS | Compliant |
