The SSI-LXR1612GD-150 is a green LED with a dome diffused lens and a wavelength of 565nm. It has a luminous intensity of 30mcd and a viewing angle of 60°. The LED is rated for a maximum operating temperature of 85°C and a minimum operating temperature of -40°C. It is available in a package quantity of 100 and is packaged in bulk with wire leads.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Lumex SSI-LXR1612GD-150 datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
Lumex SSI-LXR1612GD-150 technical specifications.
| Package/Case | T |
| Color | Green |
| Current | 25mA |
| Forward Current | 20mA |
| Height | 0.472inch |
| Illumination Color | Green |
| Lead Free | Lead Free |
| Lens Color | Green |
| Lens Style | Dome |
| Lens Transparency | Diffused |
| Luminous Intensity | 30mcd |
| Max Operating Temperature | 85°C |
| Min Operating Temperature | -40°C |
| Package Quantity | 100 |
| Packaging | Bulk |
| RoHS Compliant | Yes |
| Termination | Wire Leads |
| Viewing Angle | 60° |
| Voltage | 2.2V |
| DC Rated Voltage | 2.6V |
| Wavelength | 565nm |
| RoHS | Compliant |
Download the complete datasheet for Lumex SSI-LXR1612GD-150 to view detailed technical specifications.
