Vertical FFC/FPC connector with 16 circuits and 16 contacts, featuring a 2.54mm pitch and IDC termination. Constructed with bronze contacts plated in tin, this female connector offers a 2A current rating and 250V voltage rating. Operating temperature range is -40°C to 105°C, with a UL94 V-0 flammability rating. Designed for free-hanging mounting, it measures 15.2mm in height, 40.6mm in length, and 2.51mm in width. This lead-free, RoHS-compliant component is packaged in a rail/tube.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Molex 15-38-8168 datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
Molex 15-38-8168 technical specifications.
| Contact Material | Bronze |
| Contact Plating | Tin |
| Current Rating | 2A |
| Flammability Rating | UL94 V-0 |
| Gender | Female |
| Height | 15.2mm |
| Lead Free | Lead Free |
| Length | 40.6mm |
| Max Operating Temperature | 105°C |
| Min Operating Temperature | -40°C |
| Mount | Free Hanging |
| Number of Circuits | 16 |
| Number of Contacts | 16 |
| Number of Positions | 16 |
| Number of Rows | 1 |
| Orientation | Vertical |
| Package Quantity | 1 |
| Packaging | Rail/Tube |
| Pitch | 2.54mm |
| RoHS Compliant | Yes |
| Series | C-Grid® SL™ 70430 |
| Termination | IDC |
| Voltage Rating | 250V |
| Width | 2.51mm |
| Wire/Cable Type | Straight |
| RoHS | Compliant |
