24-circuit, female, straight FFC/FPC connector with a 2.54mm pitch. Features tin-plated bronze contacts, a 2A current rating, and a 250V voltage rating. Designed for free-hanging, cable mounting with IDC termination. Operates within a -40°C to 105°C temperature range and boasts a UL94 V-0 flammability rating. Lead-free and RoHS compliant.
Voltage Rating250V
Current Rating2A
MountingFree Hanging, Cable
Quick Jump:
Technical Specifications
Molex 15-38-8240 technical specifications.
General
Contact Material
Bronze
Contact Plating
Tin
Current Rating
2A
Flammability Rating
UL94 V-0
Gender
Female
Height
15.2mm
Lead Free
Lead Free
Length
60.9mm
Max Operating Temperature
105°C
Min Operating Temperature
-40°C
Mount
Free Hanging, Cable
Number of Circuits
24
Number of Contacts
24
Number of Positions
24
Number of Rows
1
Orientation
Straight
Package Quantity
1
Packaging
Rail/Tube
Pitch
2.54mm
RoHS Compliant
Yes
Series
C-Grid® SL™ 70430
Termination
IDC
Voltage Rating
250V
Width
2.51mm
Wire/Cable Type
Straight
Compliance
RoHS
Compliant
Datasheet
Molex 15-38-8240 Datasheet
Download the complete datasheet for Molex 15-38-8240 to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
