This female rectangular connector features a 4-position, 2-row design with a current rating of 18A and a maximum operating temperature of 125°C. It is rated for 600V and meets the IP67 rating for dust and water resistance. The connector is made from a UL94 V-0 material and is RoHS compliant.
Molex 19418-0004 technical specifications.
| Color | Black |
| Current Rating | 18A |
| Flammability Rating | UL94 V-0 |
| Gender | Female |
| Glow Wire Compliant | Non-compliant |
| Length | 22.15mm |
| Max Operating Temperature | 125°C |
| Min Operating Temperature | -40°C |
| Max Voltage Rating (AC) | 600V |
| Number of Contacts | 4 |
| Number of Positions | 4 |
| Number of Rows | 2 |
| Orientation | Straight |
| Package Quantity | 312 |
| Packaging | Bulk |
| Pitch | 5.84mm |
| Ratings | IP67 |
| RoHS Compliant | Yes |
| Series | 19418 |
| Termination | Crimp |
| Voltage Rating (AC) | 600V |
| Width | 28.86mm |
| RoHS | Compliant |
No datasheet is available for this part.
