Male, straight, signal crimp terminal for flexible flat cable (FFC) / flexible printed circuit (FPC) applications. Features brass contacts with tin, copper, and brass plating, rated for a maximum current of 17A and operating temperatures from -40°C to 105°C. Designed for cable mounting with a 5.03mm pitch, accommodating wire gauges from 20AWG to 14AWG. This low halogen, RoHS compliant component is supplied in bulk packaging.
MountingCable
Quick Jump:
Technical Specifications
Molex 39-00-0297 technical specifications.
General
| Contact Gender | Male |
| Contact Material | Brass |
| Contact Plating | Tin, Copper, Brass |
| Contact Type | Signal |
| Depth | 5.3mm |
| Gender | Male |
| Halogen Free | Low Halogen |
| Height | 4.8mm |
| Length | 22mm |
| Max Current Rating | 17A |
| Max Operating Temperature | 105°C |
| Min Operating Temperature | -40°C |
| Mount | Cable |
| Number of Rows | 1 |
| Orientation | Straight |
| Package Quantity | 6000 |
| Packaging | Bulk |
| Pitch | 5.03mm |
| Reach SVHC Compliant | Unknown |
| RoHS Compliant | Yes |
| Series | 1190 |
| Shielding | Unshielded |
| Termination | Crimp |
| Wire Gauge (Max) | 14AWG |
| Wire Gauge (Min) | 20AWG |
| Wire/Cable Gauge | 20AWG |
Compliance
| RoHS | Compliant |
