Rectangular power connector featuring 14 male pin contacts arranged in 2 rows with a 4.2mm pitch. This free-hanging, cable-mount plug offers a 13A current rating and a 600V voltage rating, with a maximum operating temperature of 105°C. Constructed with low halogen materials and a natural color, it meets UL, CSA, and TUV approvals, and is RoHS compliant. Termination is via crimp, with dimensions of 30.6mm length and 23.9mm depth.
Voltage Rating600V
Current Rating13A
MountingFree Hanging, Cable
Quick Jump:
Technical Specifications
Molex 39-01-3143 technical specifications.
General
Approvals
UL, CSA, TUV
Color
Natural
Contact Gender
Male
Contact Type
Male Pin
Current Rating
13A
Depth
23.9mm
Flammability Rating
UL94 V-2
Gender
Male
Glow Wire Compliant
Non-compliant
Halogen Free
Low Halogen
Length
30.6mm
Max Operating Temperature
105°C
Min Operating Temperature
-40°C
Max Voltage Rating (DC)
600.6kV
Mount
Free Hanging, Cable
Number of Contacts
14
Number of Positions
14
Number of Rows
2
Orientation
Straight
Package Quantity
1
Packaging
Bulk
Pitch
4.2mm
Reach SVHC Compliant
Unknown
RoHS Compliant
Yes
Row Spacing
0.165inch
Series
Mini-Fit® Jr™ 5559
Termination
Crimp
Voltage Rating
600V
Compliance
RoHS
Compliant
Datasheet
Molex 39-01-3143 Datasheet
Download the complete datasheet for Molex 39-01-3143 to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
Product Images
