Rectangular power connector, 3 circuits, 3 contacts, female socket, receptacle, straight orientation, free hanging/cable mount, 4.2mm pitch. Features a 9A current rating, 250V AC/DC working voltage, and 600V AC/DC maximum voltage rating. Constructed from Nylon/Polyamide with a UL94 V-0 flammability rating. Accommodates wire gauges from 20AWG to 16AWG. Approvals include UL, CSA, and TUV.
Sign in to ask questions about the Molex 39-01-4030 datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
Molex 39-01-4030 technical specifications.
| Approvals | UL, CSA, TUV |
| Body Material | Nylon, Polyamide |
| Package/Case | SIL |
| Color | Natural, White |
| Contact Gender | Female |
| Contact Type | Female Socket |
| Current Rating | 9A |
| Depth | 20.6mm |
| Diameter | 4.2mm |
| Flammability Rating | UL94 V-0 |
| Gender | Receptacle |
| Glow Wire Compliant | Non-compliant |
| Halogen Free | Low Halogen |
| Height | 10.2mm |
| Housing Color | Natural |
| Lead Free | Lead Free |
| Length | 13.8mm |
| Material | Nylon |
| Max Current Rating | 12A |
| Max Operating Temperature | 105°C |
| Min Operating Temperature | -40°C |
| Max Voltage Rating (AC) | 600V |
| Max Voltage Rating (DC) | 600V |
| Mount | Free Hanging, Cable |
| Number of Circuits | 3 |
| Number of Contacts | 3 |
| Number of Poles | 3 |
| Number of Positions | 3 |
| Number of Rows | 1 |
| Orientation | Straight |
| Package Quantity | 7500 |
| Packaging | Bulk |
| Pitch | 4.2mm |
| Reach SVHC Compliant | Unknown |
| RoHS Compliant | Yes |
| Series | Mini-Fit® Jr™ 5557 |
| Termination | Crimp |
| Voltage Rating | 600V |
| Voltage Rating (AC) | 250V |
| DC Rated Voltage | 250V |
| Width | 10.2mm |
| Wire Gauge (Max) | 16AWG |
| Wire Gauge (Min) | 20AWG |
| Working Voltage | 250V |
| RoHS | Compliant |
