20-position, dual-row, straight male plug connector featuring 3mm pitch and male pin contacts. Rated for 5A current and 250V operating supply voltage, with a maximum DC voltage rating of 176.25kV. This crimp termination connector has a black housing, operates between -40°C and 105°C, and supports panel or cable mounting. Dimensions include a 46.84mm length, 16.2mm width, and 19.1mm depth.
Current Rating5A
MountingPanel, Cable
Quick Jump:
Technical Specifications
Molex 44300-2000 technical specifications.
General
| Color | Black |
| Contact Gender | Male |
| Contact Type | Male Pin |
| Current Rating | 5A |
| Depth | 19.1mm |
| Gender | Male |
| Glow Wire Compliant | Non-compliant |
| Housing Color | Black |
| Length | 46.84mm |
| Max Operating Temperature | 105°C |
| Min Operating Temperature | -40°C |
| Max Voltage Rating (DC) | 176.25kV |
| Mount | Panel, Cable |
| Number of Contacts | 20 |
| Number of Positions | 20 |
| Number of Rows | 2 |
| Operating Supply Voltage | 250V |
| Orientation | Straight |
| Package Quantity | 1 |
| Packaging | Bulk |
| Pitch | 3mm |
| Reach SVHC Compliant | No |
| RoHS Compliant | Yes |
| Row Spacing | 0.118inch |
| Series | Micro-Fit 3.0 BMI™ 44300 |
| Termination | Crimp |
| Width | 16.2mm |
Compliance
| RoHS | Compliant |
Datasheet
Molex 44300-2000 Datasheet
Download the complete datasheet for Molex 44300-2000 to view detailed technical specifications.
This datasheet cannot be embedded due to technical restrictions.
