Receptacle header with female, signal contacts featuring gold-plated bronze construction. Designed for cable mounting with a straight orientation, this unshielded component supports a 1A current rating and 125V voltage rating. It accommodates wire gauges from 28 to 32 AWG with a maximum wire/cable diameter of 0.33mm. Operating within a temperature range of -40°C to 85°C, this lead-free, RoHS-compliant product is supplied on a tape and reel in a package quantity of 20,000.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Molex 50516-8041 datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
Molex 50516-8041 technical specifications.
| Contact Gender | Female |
| Contact Material | Bronze |
| Contact Plating | Gold |
| Contact Type | Signal |
| Current Rating | 1A |
| Depth | 1.07mm |
| Gender | Receptacle |
| Height | 1.25mm |
| Lead Free | Lead Free |
| Length | 3.55mm |
| Max Current Rating | 1A |
| Max Operating Temperature | 85°C |
| Min Operating Temperature | -40°C |
| Mount | Cable |
| Orientation | Straight |
| Package Quantity | 20000 |
| Packaging | Tape and Reel |
| RoHS Compliant | Yes |
| Series | 50516 |
| Shielding | Unshielded |
| Termination | Crimp |
| Voltage Rating | 125V |
| Wire Gauge (Max) | 28AWG |
| Wire Gauge (Min) | 32AWG |
| Wire/Cable Diameter | 0.33mm |
| Wire/Cable Gauge | 32AWG |
| RoHS | Compliant |
