Vertical FFC/FPC ZIF board connector, receptacle, with 16 contacts and 16 positions on a 2mm pitch. Features bronze contacts with tin plating, rated for 1A current and 50V AC/DC voltage. Operates within a temperature range of -20°C to 80°C, with a 3.5mm depth and 21.3mm length. This RoHS compliant component is designed for through-hole termination and is supplied in trays.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Molex 52030-1629 datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
Molex 52030-1629 technical specifications.
| Contact Material | Bronze |
| Contact Plating | Tin |
| Current Rating | 1A |
| Depth | 3.5mm |
| Gender | Receptacle |
| Length | 21.3mm |
| Max Operating Temperature | 80°C |
| Min Operating Temperature | -20°C |
| Max Voltage Rating (AC) | 50V |
| Number of Circuits | 16 |
| Number of Contacts | 16 |
| Number of Positions | 16 |
| Number of Rows | 1 |
| Orientation | Vertical |
| Package Quantity | 1500 |
| Packaging | Tray |
| Pitch | 2mm |
| Reach SVHC Compliant | Unknown |
| RoHS Compliant | Yes |
| Series | 52030 |
| Stackable | No |
| Termination | Solder |
| Voltage Rating | 50V |
| DC Rated Voltage | 50V |
| RoHS | Compliant |
Download the complete datasheet for Molex 52030-1629 to view detailed technical specifications.
