50-position, 2-row RJ11 modular connector with a right-angle, surface-mount orientation. Features gold-plated bronze contacts, a 0.635mm pitch and 1.27mm row spacing, rated for 100V AC and 500mA. This white, low halogen, lead-free housing offers a 47.63mm length, 26.5mm depth, and 6.64mm height, operating between -20°C and 90°C.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Molex 53856-5070 datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
| Contact Material | Bronze |
| Contact Plating | Gold |
| Current Rating | 500mA |
| Depth | 26.5mm |
| Gender | Male |
| Halogen Free | Low Halogen |
| Height | 6.64mm |
| Housing Color | White |
| Lead Free | Lead Free |
| Length | 47.63mm |
| Max Operating Temperature | 90°C |
| Min Operating Temperature | -20°C |
| Max Voltage Rating (AC) | 100V |
| Mount | Surface Mount |
| Number of Circuits | 50 |
| Number of Contacts | 50 |
| Number of Positions | 50 |
| Number of Rows | 2 |
| Orientation | Right Angle |
| Packaging | Tray |
| Pitch | 0.635mm |
| Radiation Hardening | No |
| Reach SVHC Compliant | No |
| RoHS Compliant | Yes |
| Row Spacing | 1.27mm |
| Series | 53856 |
| Termination | Solder |
| Voltage Rating (AC) | 100V |
| Width | 6.64mm |
| RoHS | Compliant |
