This male, straight, unshielded USB connector features a 6-position, 6-contact configuration with IDC termination. Constructed from polycarbonate with bronze contacts plated in gold and tin, it offers a 1.5A current rating and 125V voltage rating. The connector operates within a -40°C to 60°C temperature range and is UL approved with a UL94 V-0 flammability rating. It is RoHS compliant and designed for flat wire/cable mounting.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Molex 90075-0035 datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
Molex 90075-0035 technical specifications.
| Approvals | UL |
| Color | Clear |
| Contact Material | Bronze |
| Contact Plating | Gold, Tin |
| Current Rating | 1.5A |
| Depth | 12.32mm |
| Flammability Rating | UL94 V-0 |
| Gender | Male |
| Halogen Free | Low Halogen |
| Housing Color | Natural |
| Lead Free | Lead Free |
| Length | 0.524inch |
| Material | Polycarbonate |
| Max Operating Temperature | 60°C |
| Min Operating Temperature | -40°C |
| Mount | Cable |
| Number of Contacts | 6 |
| Number of Ports | 1 |
| Number of Positions | 6 |
| Orientation | Straight |
| Package Quantity | 1 |
| Packaging | Bulk |
| Pitch | 1.02mm |
| Radiation Hardening | No |
| Reach SVHC Compliant | Unknown |
| RoHS Compliant | Yes |
| Series | 90075 |
| Shielding | Unshielded |
| Termination | IDC |
| Voltage Rating | 125V |
| DC Rated Voltage | 125V |
| Width | 6.6mm |
| Wire/Cable Type | Flat |
| RoHS | Compliant |
