This 9-position female connector features a metal body with a zinc plating, a copper alloy contact with gold plating, and a nylon dielectric material. It has a current rating of 5A and a voltage rating of 1kV, with a maximum operating temperature of 125°C and a minimum operating temperature of -65°C. The connector is lead-free and has a packaging of 750 pieces in bulk.
Checking distributor stock and pricing after the page loads.
Sign in to ask questions about the Molex DEUH-9S-FO datasheet using AI. Get instant answers about specifications, features, and technical details, ideal for finding information in larger documents.
Sign In to ChatWidest selection of semiconductors and electronic components in stock and ready to ship ™
| Body Material | Metal, Steel |
| Body Plating | Zinc |
| Package/Case | Metal |
| Color | Black |
| Contact Material | Copper Alloy |
| Contact Plating | Gold |
| Contact Type | Signal |
| Current Rating | 5A |
| Depth | 12.55mm |
| Dielectric Material | Nylon |
| Gender | Female |
| Housing Color | Black |
| Lead Free | Lead Free |
| Length | 30.81mm |
| Mating Cycles | 500 |
| Max Current Rating | 5A |
| Max Operating Temperature | 125°C |
| Min Operating Temperature | -65°C |
| Mount | Free Hanging, Cable |
| Number of Contacts | 9 |
| Number of Positions | 9 |
| Number of Rows | 2 |
| Orientation | Straight |
| Package Quantity | 750 |
| Packaging | Bulk |
| Reach SVHC Compliant | No |
| Series | D*U |
| Voltage Rating | 1kV |
| Width | 10.92mm |
| Wire Gauge (Max) | 28AWG |
| Wire Gauge (Min) | 20AWG |
| RoHS | Compliant |
